Body:
Swamp Ash / Sassafras
Neck heel:
Special contoured for easy upper frets access
Unique Features:
Bolt-on (6 screws mounted in ferrules) construction with contoured heel

Construction:
Bolt-on neck joint with a 6-screw mounted on ferrules
Scale:
34.25" (870 mm)
Neck:
1-pc / Hard Rock Maple TEW
Radius:
20" (508 mm)
Fingerboard:
Pau Ferro / Rosewood
Markers & Inlays:
Acrylic block markers
Original Luminlay™ side dots, SGM-23 Super Green in Black pipe, 3 mm
Neck dimensions:
Width at nut – 38.5 mm
Width XII fret – 58.0 mm
Width XXIV fret – 66.0 mm
Thickness I fret – 21.0 mm
Thickness XII fret – 23.0 mm
Truss rod:
Double action truss rod
Frets:
24 jumbo, Ferd Wagner 9665, 18% N/S Hard
Crown dimensions: 2.64 × 1.20 mm (w × h)
Headstock:
Straight; topped with chosen body wood
Body matching finish
Nut:
Plastic nut
Tuners layout:
4 in line

Pickups / Electronics:
J-J / Mayones Velvetrone® Gallant Split Coil Pickups
Mayones Musashi Nitōryū preamp (3 band EQ)
Control:
1 × Volume (push-pull or miniswitch for Active/Passive), 1 x Balance, 1 × Middle, 1 x Treble / Bass, 1 × PassiveTone.
Other switching and control options available on request (extra fee may be required)
Headphone Amp
1/8" Stereo Jack Aux Input and Headphone out
Rechargeable Internal Power Supply /w backup 9v battery compartment
USB-C Charging Port w/ Dedicated Charger
Knobs:
Standard metal dome knob(-s)

Bridge:
Mayones Big Foot Bridge
string-to-string spacing: 20 mm
Strings:
44 -106 Roundwound [4-string]
Tuners:
Hipshot HB6C Ultralite Tuners
Additional equipment:
Schaller Security Straplocks
Switchcraft jack
Separate 9V battery compartment(-s)
Hardware colour:
Chrome (CR)
Bag / case:
Mayones Hybrid Bass Case
